2188
New
- Latchbolt is withdrawn by pull handle inside or key outside.
- Deadbolt is locked or unlocked by key from either side.
- One full turn of the key clockwise operates first throw and a second full turn double throws the bolt. Latchbolt can be held back by anti-clockwise turn of the handle whilst bolt is withdrawn.
More info
- Mechanism: 5 pin cylinder.
- Cylinder finish: Brass.
- Case finish: Polished brass.
- Keys Supplied: 3.
- Keyed Alike: please contact us.
- Master Keyed: please contact us.
- Differs: 20,000.
- Door thickness: 35mm - 60mm.
- (this lock is an alternative to the Chubb 4L69, very slight adjustments may be needed).
- Case sizes are: 1332 Backset = 60mm, case width = 92mm & 1334 backset = 50mm, case width = 73mm. All other dimensions are: Case height = 76mm, handle projection = 21mm & case depth = 27mm.
